Product Description
An axial lead 2x7mm resistor type fast quick blow fast-acting micro cartridge pico fuse is a small, cylindrical device that is designed to protect an electrical circuit from overcurrent or short circuits.
The "axial lead" design means that the fuse has two wires that extend from opposite ends of the cylinder, which are used to connect the fuse to the circuit. The "2x7mm" size refers to the dimensions of the cylinder, with a diameter of 2mm and a length of 7mm.
1. Axial lead: The fuse has leads that are placed at the ends of the cylindrical body of the fuse. These leads are used for connecting the fuse to a circuit.
2. Resistor type: The fuse is designed with a resistor element that helps to limit the current flow in the circuit. This can help to protect the circuit components from damage.
3. Fast-acting: The fuse is designed to respond quickly to overcurrent conditions in the circuit, and to open the circuit within a short period of time. This helps to prevent damage to the circuit components.
4. Quick blow: The fuse is designed to respond quickly to high current surges, such as those that may occur during a short circuit. This helps to prevent damage to the circuit components.
5. Micro cartridge: The fuse has a small cartridge body that is designed to fit into tight spaces and small circuit boards.
Product Data
| Product name: | Micro Pico Fuse | Shape: | Resistor |
|
Rated voltage: |
125V 250V | Rated current: | 200mA~16A |
| Leads: | Axial | Operating Temperature Range: | -55℃ To +125℃ |
| Standard: | UL248-14 | Soldering Peak: | 260℃. 10 Sec. (IEC 60068-20) |
Product Details
Electrical Characteristics
Product Appilance
Axial lead fast-acting micro cartridge pico fuses are commonly used in electronic circuits to provide overcurrent protection. These fuses are designed to open quickly in response to excessive current flow, thus protecting sensitive electronic components from damage.
Some common applications of axial lead fast-acting micro cartridge pico fuses include:
1. Power supplies: Axial lead fast-acting micro cartridge pico fuses are commonly used in power supply circuits to protect against overcurrent conditions. They help to prevent damage to power supply components and ensure reliable operation.
2. Audio equipment: These fuses are also used in audio equipment such as amplifiers and speakers to protect against overcurrent conditions that can damage the sensitive electronics.
3. Industrial equipment: Axial lead fast-acting micro cartridge pico fuses are used in various industrial equipment, including machinery and control systems, to protect against overcurrent conditions that can cause equipment failure or even safety hazards.
4. Automotive electronics: Pico fuses are used in automotive electronics to protect against overcurrent conditions that can cause damage to the electronic components and even cause a fire.
5.Consumer electronics: These fuses are used in various consumer electronics devices such as televisions, DVD players, and gaming consoles to protect against overcurrent conditions that can cause damage to the device and potentially pose a safety hazard to the user.
Overall, the axial lead fast-acting micro cartridge pico fuse is a versatile component that finds use in a wide range of electronic applications where reliable overcurrent protection is required.
Factory Tour
Dongguan Senreach Electronics Co., Ltd, founded in 2011, is a professional circuit protection components manufacturer and programme supplier in China. We have 20 years' experience in manufacturing fuse, fuse holder, circuit breaker, thermal protector, ntc sensor and etc.
With variety of advanced manufacturing and testing equipment, we adopt perfect quality management system to ensure that every single piece of our components are safe and stable. Our operations are ISO9001:2000-certified and products meet international standards.
We are specialized in developing, manufacturing and selling circuit protection components for over-current, over-temperature and over-voltage applications with kinds of performance, types and specifications. Our products are widely used in consumer electronics, automobiles, vessels, communication device, power supply, new energy, photovoltaic and other fields.
Workshop
Workshop
Workshop
Workshop
Workshop
Workshop
Workshop
Workshop
Why choose Us
Price Advantage
We have our own factory which enable us to offer the first-hand price to our customers.
Quality Assurance
Automatic production
Full inspection
Full tested
Factory Wholesale
We have open stock in warehouse. So we can finish order in a short lead time and make fast delivery.
One-window service
Selection recommendation
Technical Support
After-sales protection
Exhibition
