The Description of L2 Series Surface Mount Panel Manual Automatic Reset Thermal Magnetic Circuit Breaker
L2 Current Protection Device Thermal Magnetic Circuit Breaker Manual Auto Reset Overcurrent Protector for Car Ocean Industry
•DC CIRCUIT BREAKERS
•POWER BREAKER
•MAIN BREAKER
-Applied to solar system, inverter, new energy vehicles, trucks, forklift and other devices.
-The circuit breaker uses temperature control and reset arm to achieve the reusable function, enables the breaker to play the
same role as switches.
Protection Circuit: Compact design enables high density circuit protection configuration. When the load exceeds the rated current, this switch reset button will automatically cut off the circuit, and thus play a role in protecting the line.This switch can be reset after a disconnect over a period of time, then you can press the reset switch to use it again.
Premium Quality: Made of durable plastic with excellent thermal conductivity and corrosion resistance, high quality and long service life. automotive, industry and ocean industry.
Waterproof function: Equipped with a waterproof protective plastic cover, dust and water resistant. You can use them in harsh environments to ensure safe operation.
Easy to install: The circuit breaker uses the panel mount design for quick & easy access.
Product Parameter
| Product Name | L1 Overload Circuit Breaker Bakelite Push Button Manual Auto Reset | Model Number |
L1 series Manual Resettable Circuit Breaker |
| Type |
Thermal/Electrical Protector Circuit Breaker |
Reset Type | Auto Manual Resettable Thermal Circuit Breaker Overload Protector |
| Rated Voltage | AC 125/250V DC 50V |
Rated Current |
3A 4A 5A 6A 7A 8A 10A 12A 15A 16A 20A 25A |
| Material | Bakelite | Mounting | Surface Mounting |
| Termination | 250" (6.35mm) quick conects or solder terminals | Temperature Rise at Terminal Block | Less than 65°C at 100% of rated current applied continuously at 25°C |
| Interrupt Capacity | 1000A (UL 1077 ) | Resettable Overload Capacity | Ten Times Rated Current |
| Method Of Operation | R Type | Application | AC socket, Motors, Tarnsforms, Battery chargers, appliances, Power supplies, extra low voltage systems, machinery |
Product Details
Products Details
Installation:
Surface mount on panel or firewall, easy to use and durable, protective stud insulators included.
Working Principle of L1 Circuit Breaker :
An overload protector (circuit breaker) protects the compressor by sensing temperature and current. It is composed of a set of normally closed contacts and bimetallic elements. The overcurrent overload protector is mounted on the outside of the compressor, in direct contact with the compressor casing and in series with the compressor windings. If the compressor cannot be started for some reason, the overloaded locked-rotor current will cause the bimetal element to heat up and bend rapidly, causing the contact to quickly trip, cutting off the current flowing through the compressor, thereby protecting the compressor. Similarly, if the motor of the compressor is abnormally heated and the temperature of the windings of the compressor is too high, the protector will heat up and trip, thereby protecting the compressor. As long as the cause of the failure is not ruled out, the compressor will start and stop with the action of the bimetallic element over and over again in the case of overcurrent and overload.
Kindly Note:
1. The breaker has a reset button that pops up when it trips, and the button cannot be pulled out manually to break the circuit.
2. The thermal breaker does not trip immediately, there is a delay based on the amount of overload.
L2 Series Bakelite Waterproof Thermal Circuit Breaker Dimension
More details
circuit breaker Application
This L2 Current Protection Device Thermal Magnetic Circuit Breaker is used in automotive industry, electrical products, winches, DC power supplies, DC sound amplifier system, electric vehicles, chargers, motors, boat, marine, RV Yacht, trailer, bus, truck, ATV and other.
